• Dimmer a taglio di fase, leading edge e trailing edge
• Tensione di ingresso 230VAC (180~295VAC)
• Funzione di PFC attivo integrata
• Custodia in plastica completamente isolata
• Modalità di funzionamento a Corrente Costante (C.C.)
• Grado di protezione IP30
• Alimentatori conformi Classe 2 unità (LPS)
• Isolamento Classe II , senza polo di terra
• Protezioni: Cortocircuito / sovra temperatura
• Raffreddamento a libera convezione d’aria
| Codice EUROTEK | Sigla MEAN WELL | Caratteristiche | Dim. LxHxP |
| ET5924 | PCD-16-350B | C.C. mode, I out 350mA; V out 24~48VDC |
84x57x29.5mm
|
ET5925 | PCD-16-700B | C.C. mode, I out 700mA; V out 16~24VDC |
84x57x29.5mm
|
| ET5926 | PCD-16-1050B | C.C. mode, I out 1050mA; V out 12~16VDC |
84x57x29.5mm
|
| ET5927 | PCD-16-1400B | C.C. mode, I out 1400mA; V out 8~12VDC |
84x57x29.5mm
|
| ET5946 | PCD-25-350B | C.C. mode, I out 350mA; V out 40~58VDC |
84x57x29.5mm
|
| ET5947 | PCD-25-700B | C.C. mode, I out 700mA; V out 24~36VDC |
84x57x29.5mm
|
| ET5948 | PCD-25-1050B | C.C. mode, I out 1050mA; V out 16~24VDC |
84x57x29.5mm
|
| ET5949 | PCD-25-1400B | C.C. mode, I out 1400mA; V out 12~18VDC |
84x57x29.5mm
|
| ET5195 | PCD-40-350B | C.C. mode, I out 350mA; V out 70~108VDC |
128x60x31.5mm
|
| ET5196 | PCD-40-500B | C.C. mode, I out 500mA; V out 45~80VDC |
128x60x31.5mm
|
| ET5197 | PCD-40-700B | C.C. mode, I out 700mA; V out 34~57VDC |
128x60x31.5mm
|
| ET5198 | PCD-40-1050B | C.C. mode, I out 1050mA; V out 22~38VDC |
128x60x31.5mm
|
| ET5199 | PCD-40-1400B | C.C. mode, I out 1400mA; V out 17~29VDC |
128x60x31.5mm
|
| ET5327 | PCD-40-1750B | C.C. mode, I out 1750mA; V out 13~23VDC |
128x60x31.5mm
|
| ET5071 | PCD-60-500B | C.C. mode, I out 500mA; V out 70~108VDC |
128x60x31.5mm
|
| ET5072 | PCD-60-700B | C.C. mode, I out 700mA; V out 50~86VDC |
128x60x31.5mm
|
| ET5073 | PCD-60-1050B | C.C. mode, I out 1050mA; V out 34~57VDC |
128x60x31.5mm
|
| ET5074 | PCD-60-1400B | C.C. mode, I out 1400mA; V out 25~43VDC |
128x60x31.5mm
|
| ET5075 | PCD-60-1750B | C.C. mode, I out 1750mA; V out 20~34VDC |
128x60x31.5mm
|
| ET5076 | PCD-60-2000B | C.C. mode, I out 2000mA; V out 18~30VDC |
128x60x31.5mm
|
| ET5069 | PCD-60-2400B | C.C. mode, I out 2400mA; V out 15~25VDC |
128x60x31.5mm
|
